Schermo della barra meccanica FL

FYL, come società impegnata principalmente nello schermo della barra meccanica FL e in altre attrezzature per macchinari idraulici, ha una propria fabbrica dotata di una linea di produzione completa per supportare la progettazione e la produzione personalizzate. Questo prodotto può essere utilizzato per intercettare particelle più grandi nelle acque reflue e può essere installato all'ingresso dell'acqua e all'assunzione di acqua. È ampiamente utilizzato negli scenari municipali, per il trattamento delle acque e la stazione di pompaggio.

Invia richiesta

Descrizione del prodotto

FL Mechanical Bar Screen

FL mechanical bar screen is a compact mechanical screen suitable for wider channels. It has good rigidity and strength, can maintain stability during operation, and is easy to operate. As a continuous automatic cleaning equipment, this product is mainly used in various municipal and industrial sewage treatment. It can also be used in pump stations and installed at water inlets and water intakes to intercept larger suspended and floating objects in sewage. It has a good cleaning effect, high efficiency, and is very convenient for maintenance.

FL Mechanical Bar Screen Feature

1. FL mechanical bar screen has a simple structure in design and manufacturing, no underwater transmission parts, easy maintenance and management, long service life and strong corrosion resistance;

2. It has high separation efficiency and small bar gap during operation, thus achieving better slag removal effect. It can be operated continuously or intermittently to achieve more efficient water treatment.

3. According to the specific usage scenario, the specific specifications and dimensions are determined. As a professional manufacturer, FYL supports customization. The finished product is easy to install. The whole machine can be placed in the tank. After installation and debugging, it can be used smoothly.

Parameter- Mechanical coarse Bar Screen

Size	YS-800	YS-1000	YS-1200	YS-1400	YS-1600	YS-1800	YS-2000
Equipment Width (mm)	800	1000	1200	1400	1600	1800	2000
Channel Width(mm)	900	1100	1300	1500	1700	1900	2100
install angel α	60°65°70°75°80°
Bar space（mm）	10、15、20、25、30、40、50、60、80、100
Speed（m/min)	1.8
Channel Depth H（mm）	OEM
Slagging height H1（mm）	400-1000（OEM，common-800）
Power （KW)	0.75-1.1			1.5-2.2
